Brokk 120DII
The world’s smallest diesel-driven demolition machine. Outstanding power in tight spaces.
WANT OUR CATALOGUE? ORDER
The world’s smallest diesel-driven demolition machine, the BROKK 120DII offers flexibility without compromise. Its small size enables it to enter through any standard door opening and makes it easy to maneuver in tight spaces. Running cordless, it can operate for a minimum of eight hours without refueling. The MarkII version comes with the full Brokk SmartConcept – SmartPowerTM, SmartDesignTM and SmartRemoteTM. And it keeps the outstanding power and performance that make Brokk machines unique.
- World's smallest diesel-driven demolition machine
- Ideal for sites that lack a reliable power supply
- Rugged and reliable Brokk SmartPowerTM
- Brokk SmartDesignTM and SmartRemoteTM
Features
SmartPower™
Green diesel motor
- Hydraulic breaker in illustrations.
Load and stability diagram available on request. - BHB 155
Performance
- Slewing speed
- 10 sec/360°
- Transport speed, max.
- 3 km/h; 1.9 mph
- Climbing inclination, max.
- 30°
Hydraulic system
- Hydraulic system capacity
- 45 l; 12 US gal
- Pump type
- Gear pump with fixed displacement
- System pressure*
- 18 MPa; 2 610 psi
- Pump flow
- 50 l/min; 13 US gal/min
Diesel performance
- Type
- Three-cylinder, water-cooled, 4-stroke engine
- Engine
- 18,5 kW; 24.8 hp diesel EPA Tier 4
- Fuel tank capacity
- 30 l; 7.9 US gal
- Engine oil volume
- 5,1 l; 1.35 US gal
- Coolant volume
- 4,4 l; 1.2 US gal
- Freezing point
- -40ºC; -40ºF
Control system
- Control type
- SmartRemote, portable control
- Signal code
- Digital
- Transfer
- Professional radio/Cable
- Range, radio
- Up to 300 m
Weight
- Machine weight**
- 1230 kg; 2712 lbs
- Recommended attachment weight
- 160 kg; 353 lbs
Noise level
- Sound power level LWA***
- 101 dB(A)
- Pump flow, 50Hz
- 50 l/min; 13.3 gal/min
- Power
- 18.5 D
- Width min.
- 780 mm; 30.7 in
- Height min.
- 1250 mm; 49.2 in
- Vertical reach (incl. breaker)
- 4300 mm; 169 in
- Horizontal reach (incl. breaker)
- 3700 mm; 146 in
*Hydraulic pressure can be increased depending on the attachment
**Excluding options and attachment
***Measured according to directive 2000/14/EC, excl. attachment
